Inductive Digital Comparator - 2149

Save 25%

Size: 2149-2 (2mm)
Price:
Rs. 35,500 Rs. 47,215

Tax included Shipping calculated at checkout

Description

Features:-

  • Built-in wireless transmission
  • IP54 Dust/waterproof
  • Reading in digital and analog
  • Display can be rotated by 320
  • Can store 10 set parameters, can be searched and recalled
  • 999 groups value can be stored
  • Touch sensor: use the sensor to transmit data, avoiding press the button to cause deformation of the dial indicator stand and affect the zero position
  • Button function: on/off, zero, data hold, measuring direction change, inch/metric conversion, data preset, absolute/incremental measurement, max./min./TIR measurement, tolerance go and no-go display, data output, analog pointer resolution and range change, print data
  • Power: rechargeable battery, for 12 hours continuous working
  • Ruby probe
  • Data output
  • Optional accessory: receiver (code 2149-RE, transmission distance is meters), printer (code ISF-DF-PRINTER)
    Code  Range Resolution Accuracy Hysteresis Reapetability Measuring Force
    2149-2 2mm/0.08" 0.1μm/0.000005" 0.05μm 0.2μm 0.3μm 0.8-1N
