High Precision Digital Indicator - 2140

Save 25%

Size: 2140-6 (0-6mm)
Price:
Rs. 24,955 Rs. 33,189

Tax included Shipping calculated at checkout

Description

Features:-

  • Linear ball bearing for ten million times use
  • ⌀28mm stem suitable for reinforced clamping
  • Absolute encoder, the original data remains after power off
  • Adjustable resolution: 0.0002mm/0.00001"
                                        0.001mm/0.00005"
                                         0.01mm/0.0005"
  • Reading in digital and analog
  • Button function: data output, tolerance, data preset, data hold, measuring direction change, max./min./TIR, power off time, on/off, mm/inch, adjust resolution
  • Power: rechargeable battery, for 24 hours continuous working
  • Ruby probe
  • With data interface
    wireless transmitter, code 7315-60, wireless receiver, code 7315-2, 7315-3
    Optional accessory: data output cable (keyboard format), code 7302-60 data output cable (serial port format), code 7305-G60
    (cable length 3m, optional cable length maximum 15m; RS232 protocol, optional RS485 protocol)
Code  Range Accuracy Hysteresis Remark
2140-6 0-6mm/0-0.24" 1.6μm 0.8μm Flat back
  • Built-in wireless
    Optional accessory:
    wireless receiver (keyboard format), code 2134-R1
    wireless receiver (serial port format), code 2134-R2
Code  Range Accuracy Hysteresis Remark
2140-6WL 0-6mm/0-0.24" 1.6μm 0.8μm Flat back
